成为第一个评论此产品的人
缺货
SKU
CPHC102407ECL1
全钢制 Arrow 车棚配围栏是一个便捷、多功能且实用的全天候遮阳和遮蔽解决方案,可在任何需要防护的地方使用。每个 Arrow 车棚都具有雪载等级,专为应对恶劣天气条件而设计。购买一个来保护您的日常车辆免受天气影响,或为您的露台或聚会区域提供遮阳。
- 采用 2 英寸方管粉末涂层钢框架,为整个装置提供稳定性和强度
- 专为更轻松、更快速的组装而设计:其独特设计具有滑配框架连接,配有引导孔和自钻螺丝,开箱即可实现更快速、更便捷的组装
- 圆形屋檐和屋顶山墙处 12 英寸的悬挑提供额外的天气防护
- 29 号重型镀锌钢侧壁与屋顶相匹配,可连接到车棚上,提供额外的天气防护
- 屋顶和侧壁板采用吸引人的炭黑色饰面
- 在美国制造,使用全球采购的材料
- 提供 10 年保修
- 雪载荷仅作参考,假设框架根据当地建筑规范和条例牢固固定。这些已使用符合 ASCE 7-05 的综合雪载荷规定进行计算。
- 雪载超载值仅供参考,假设框架根据当地建筑规范和市政法规牢固固定。这些载荷已使用符合 ASCE 7-05 的综合雪载荷和风载荷规定进行计算。
- Featuring a 2 in. square tube powder-coated steel frame, which provides stability and strength to the unit
- Built for easier, faster assembly: its unique design features a slip-fit frame connection with pilot holes and self-drilling screws for assembly that's faster, more convenient right out of the box
- Rounded roof eaves and 12 in. overhang at the roof gables offer additional protection from the elements
- A heavy-duty 29-gauge galvanized steel sidewall matches the roof and can be attached to the Carport to provide extra protection from the elements
- The roof and sidewall panels come in an attractive Charcoal finish
- 在美国制造,使用全球采购材料
- 享有10年质保
- Snow load is given as reference only and assume a securely anchored frame according to local building codes and ordinances. These have been calculated using combined snow load provisions in accordance with ASCE 7-05.
- The snow overload value is for reference only and assumes a firmly anchored framework in accordance with local building codes and municipal regulations. These loads were calculated using the combined snow load and wind load provisions in accordance with ASCE 7-05.
| 制造商型号 | CPHC102407ECL1 |
|---|---|
| UPC | 026862124982 |
| 品牌 | Arrow |
| 货物类型 | LTL |
| 制造商零件号 | CPHC102407ECL1 |
| 尺寸 | 10' x 24' |
| 屋顶类型 | 镀锌钢屋顶 |
| 框架材质 | 钢铁 |
| 框架颜色 | 黑 |
| 外罩颜色 | 木炭 |
| 墙面颜色 | 木炭 |
| 屋顶颜色 | 木炭 |
| 屋顶饰边颜色 | 木炭 |
| 需要组装(是/否) | 是 |
| 随附储物袋(是/否) | 否 |
| 防泼水(是/否) | 是 |
| 防水(是/否) | 否 |
| 额定雪荷载(磅/平方英尺) | 35 |
| 额定抗风(英里/小时) | 75 |
| 总储物面积(平方英尺) | 234 |
| 地基长度(英寸) | 300 |
| 地基宽度(英寸) | 132 |
| 门/入口高度(英寸,外侧拉链) | 82 |
| 门/入口底部宽度(英寸,外侧拉链) | 116 |
| 组装后内部深度(英寸) | 290.75 |
| 组装后内部宽度(英寸) | 116 |
| 组装后内部高度(英寸) | 96.4 |
| 组装后外部深度(英寸) | 290.75 |
| 组装后外部宽度(英寸) | 120 |
| 组装后外部高度(英寸) | 98.4 |
| 包装内容 | 车棚框架和屋顶、1块侧墙围挡、紧固件和安装说明 |
| 箱子数量 | 10 |
| 装运长度(含托盘,如适用)(英寸) | 71.06 |
| 装运宽度(含托盘,如适用)(英寸) | 30.5 |
| 装运高度(含托盘,如适用)(英寸) | 31.7 |
| 装运重量(含托盘,如适用)(磅) | 950 |
| 质保 | 10 年 |
